A complete guide for safe machinery and equipment move
Moving heavy machinery, sometimes called machine shifting, requires a defined sequence covering assessment, dismantling, lifting, transport, reassembly and testing. The exact method depends on the machine, the route, the site and whether production continues around the work.
How do you move heavy machinery safely?
A safe machinery move follows a planned sequence: assess the equipment and route, define the lifting and transport method, dismantle and protect the machine, rig and move it, transport it where required, reassemble and align it, then complete inspection and testing before production restarts.
The International Labour Organization estimates that 395 million workers worldwide sustain a non-fatal work injury each year. A heavy machinery move combines lifting, stored energy, moving vehicles, suspended loads and changing work zones, so hazards and controls should be agreed before work begins and reviewed as site conditions change.
1. Complete a pre-move assessment
Record the machine dimensions, weight, centre of gravity, lifting points and any manufacturer instructions. Check the route from the existing position to the loading area and from delivery point to final position, including floor loading, door openings, turning space, overhead restrictions and access for lifting equipment.
2. Build the moving plan
Define responsibilities, sequence the move and identify the equipment, labour and permits required. The plan should include electrical, hydraulic and pneumatic isolation; dismantling; packing; lifting; transport; unloading; reassembly and testing.
Transport and lifting requirements vary by country, so the move must be checked against the rules that apply at the origin site, the destination site and along the transport route. Cross-border projects may also need customs clearance, escorts, permits or route approvals, depending on the machinery and journey.
3. Dismantle and protect the machinery
Follow the manufacturer’s instructions and record the machine condition before work starts. Match-mark components, photograph connections and isolate electrical, hydraulic and pneumatic systems. Sensitive assemblies may need separate crates, shock protection, moisture control or other packaging selected for the equipment and journey.
4. Plan and execute the rigging
Select lifting equipment and rigging hardware from the verified load data and site conditions. The method may involve cranes, forklifts, gantries, skates, jacks or combinations of these systems.
For a deeper explanation of load handling and positioning, see our guide to rigging services and riggers.
5. Transport the machinery
Use a transport provider and vehicle configuration suitable for the loaded weight and dimensions. Route surveys may be required for bridge capacity, road width, overhead restrictions, street furniture and delivery access. The transport plan should also account for the receiving site’s unloading sequence so lifting equipment and installation teams are ready when the load arrives.
6. Unload, position and reassemble
Unload onto a prepared route and move the machine into its final position using the approved lifting or movement method. Reassemble components from the match-marking records, reconnect services and complete mechanical checks before energisation.
Where positional tolerances are tight, precision measurement and alignment can support floor marking, levelling and verification.
Reinstallation at the new position follows the same stages as machinery installation: assembly, alignment, connection and testing.
7. Test and hand over
Inspect the machinery for transport or handling damage, verify guards and connections, and complete the required mechanical, electrical and functional checks. Any issue identified during inspection should be documented, assessed and resolved before the machine is returned to production.
A machinery-relocation example
For a relocation from Germany to Trutnov in the Czech Republic, Beck & Pollitzer unloaded and moved production equipment to a fourth-floor installation area. The seven-person team worked from risk assessments, method statements and lifting plans, using 5-tonne forklifts and two 55-tonne mobile cranes. The work took 528 project hours.
The same end-to-end scope can cover machine relocation from dismantling through reinstallation, with lifting, transport and installation planned as one work package.
Frequently asked questions
Common systems include mobile and overhead cranes for vertical lifts, forklifts for loading and short moves, hydraulic gantries where crane access is limited, jacks for raising a machine onto skates, and machine skates for rolling it across the floor. Lifting frames and spreader beams help distribute the load during a lift.
Cost depends on machine weight and dimensions, dismantling requirements, lifting method, transport distance, route constraints, packaging, permits and reinstallation scope. A site and equipment assessment is needed before a reliable quotation can be produced.
It depends on how the machine’s weight and dimensions compare with the available lifting capacity, door openings, floor loading and transport limits. Moving a machine whole reduces reassembly and realignment work, while dismantling reduces the size and weight of each lift. Manufacturer guidance and the route survey usually decide which approach is used.
The machine should be isolated and the damage documented before reassembly or recommissioning continues. The project team can then determine whether inspection, repair, replacement parts or insurer involvement is required before the equipment is returned to service.
If you are planning a machinery move and want to discuss lifting, transport or installation requirements, contact Beck & Pollitzer.
