Conveyor installation: A step-by-step guide
Conveyor installation turns a conveyor design into a working material handling system. It covers site evaluation, conveyor assembly, electrical and control connections, testing and commissioning, carried out in a sequence that keeps each stage ready for the next.
This guide sets out the installation steps for industrial conveyor systems in manufacturing plants, warehouses and distribution centres. For an overview of conveyor types and how they are used, see our conveyor systems guide.
What does conveyor installation involve?
A conveyor system installation normally follows six stages: site evaluation, design and planning, safety planning, mechanical installation, electrical installation, and testing and commissioning. Mechanical and electrical work often overlap on larger systems, so the sequence needs to be agreed before the first section arrives on site.
Conveyor installation steps
1. Evaluate the site
Assess the installation area against the conveyor layout. Confirm the available space, the workflow the system has to support and how it will connect to existing equipment. Check that the floor or supporting structure can carry the weight of the conveyor and its operational loads, and that power, compressed air and other utilities are available where they are needed.
Delivery routes also need checking. Long conveyor sections, drive units and mezzanine steelwork have to reach the installation area without blocking other work.
2. Confirm the design and installation plan
Work with the system designer and conveyor manufacturer to confirm the design against operational requirements and safety standards. The installation plan should set out timelines, resources, the order in which sections are installed and the main risks.
On larger or multi-trade projects, a project manager can oversee the installation sequence, interfaces and changes from start to finish. Project management provides one point of control where several trades and suppliers are working to the same programme.
3. Plan safety features and site controls
The design should include safety features such as emergency stops, guarding and sensors, and comply with the safety standards that apply where the system is installed. In Europe, for example, EN 620:2021 sets safety requirements for fixed belt conveyors that carry bulk materials.
The installation itself needs its own controls: lifting plans for heavy sections, permits for electrical and hot work, exclusion zones and safe access for work on elevated conveyors and platforms.
4. Mechanical installation and conveyor assembly
Mark out the conveyor route, then level the floor fixings and install any guideways. Conveyor assembly follows: frames, drives, motors, belts or rollers and transfer units, connected section by section to the manufacturer’s instructions.
Supporting structures such as mezzanines, platforms, pillars and cable tray supports are installed as the layout requires. Sections are then aligned so belts track correctly and products transfer smoothly between units.
5. Electrical installation
Install control panels, cable containment, sensors and wiring, and connect the conveyor to the wider control and automation system. The control system is then configured so the conveyor operates as designed, and electrical connections are tested before power-up.
On large systems the electrical scope can be substantial. For an automated warehouse in Warrington, Beck & Pollitzer installed 6,500 metres of electrical containment on conveyor systems, alongside 20 PLC cabinets and 88 miles of control cable.
6. Test, commission and hand over
Run the conveyor empty first, then introduce loads gradually to confirm that it handles operational demands. Record and resolve any issues found during testing. Before handover, operators and maintenance staff should be trained on running and maintaining the system safely, and test results and settings should be included in the handover documentation.
Conveyor installation in practice
On larger automation programmes, the installation method has to work consistently across multiple sites.
For a returning automotive tyre client, Beck & Pollitzer carried out warehouse automation installations at four facilities in Germany and Spain, including conveyor guideways, conveyor assembly, platforms and electrical works across more than 200,000 hours.
Conveyor installations of this kind often form part of a wider warehouse automation scope. Beck & Pollitzer’s machinery installation services bring conveyor assembly, electrical installation and commissioning support together under one team.
Frequently asked questions
A conveyor installer assembles and positions conveyor frames, drives and belts or rollers, sets out and levels the system, and connects it to power and controls. Installers also support testing and commissioning so that faults are found before the system goes into production.
Yes. Work can be phased, carried out in segregated areas or scheduled around shutdown windows, particularly where the new conveyor connects to equipment that is already running.
Conveyor installation is the physical work of assembling, positioning, levelling and connecting the system. Commissioning follows it and proves that the conveyor, its controls and its interfaces with other equipment operate as designed under load, before the system is handed over for production.
